Glass Veil

Home » 9 Surface Veils 9 Glass Veil

In a FRP laminate, surface mat is present under the top coat (gel coat) which creates a weather  resistant layer. Properly impregnated and cured surface mat will protect the inner glass-resin matrix. This will surely enhance life of your composite parts. At the same time, surface mat also reinforces the gel coat layer. While applying a layer of surface mat, always be generous in using resin. Ideally, glass-to-resin ratio for laminating surface mat should be at least 1:6 to a good 1:10. For instance, to lay a 30 gr/m2 surface mat, use 250 to 300 grams of resin per meter square.

Application with Glass Veil

Most important aspect is to create a barrier. In some aggressive environments where composite parts are constantly exposed / submerged into acidic waters or chemicals, a layer of surface mat is applied on both sides of such parts. One classical example is cooling tower panels.

Glass Surface Mat
Product Code
CV201P
CV201CP
Description
30 gsm, 1000 mm, 300 lm
30 gsm, 1000 mm, 300 lm
